Application:Fixing of building formwork, fixing of items on concrete buildings
Wire material:55#/1055/S55C
Finshed:Electro galvanized,coating
Surface color:Blue,white,black,yellow
Surface Hardness:48＜HRC＜50
Core Hardness: 53＜HRC＜58
Head type:flat head(support customization)
Shank type:spiral
Point type:Diamond
Primary packing(carton):400g/boxes,25 boxes/carton
Primary packing(bulk):25kg/bag
Model:
|
Model |
Shank diameter |
Length |
Approximate quanity/boxes |
Single weight |
||
|
mm |
inch |
mm |
inch |
|||
|
CMS25 |
3.2mm |
0.126″ |
25mm |
1″ |
282pcs |
1.35g |
|
CMS30 |
3.2mm |
0.126″ |
30mm |
1-3/16″ |
166 pcs |
2.29g |
|
CMS50 |
3.6mm |
0.141″ |
50mm |
2″ |
99pcs |
3.84g |
|
CMS63 |
4.0mm |
0.157″ |
63mm |
2-1/2″ |
63 pcs |
6g |
|
CMS75 |
3.7mm |
0.146″ |
75mm |
3″ |
49 pcs |
7.74g |
|
CMS100 |
4.5mm |
0.177″ |
100mm |
4″ |
31 pcs |
12g |
|
CMS125 |
4.5mm |
0.177″ |
125mm |
5″ |
25 pcs |
15.17g |
