concrete nails smooth

Application:Fixing of building formwork, fixing of items on concrete buildings

Wire material:45#/1045/S45C

Finshed:Electro galvanized,coating

Surface color:Blue, black,yellow,white

Surface Hardness:43＜HRC＜45

Core Hardness: 48＜HRC＜52

Head type:flat head(support customization)

Shank type:Smooth

Point type:Diamond

Primary packing(carton):400g/boxes,25 boxes/carton

Primary packing(bulk):25kg/bag

Model:

Model	Shank diameter		Length		Approximate quanity/boxes	Single weight
Model	mm	inch	mm	inch	Approximate quanity/boxes	Single weight
SCM20	2.0mm	0.102″	20mm	3/4″	693 pcs	0.55g
SCM25	2..8mm	0.114″	25mm	1″	290 pcs	1.31g
SCM30	2.8mm	0.126″	30mm	1-3/16″	225 pcs	1.69g
SCM40	2.8mm	0.138″	40mm	1-5/8″	130 pcs	2.93g
SCM50	3.4mm	0.146″	50mm	2-″	101 pcs	3.75g
SCM60	3.7mm	0.161″	60mm	2-3/8″	66 pcs	5.74g
SCM70	4.1mm	0.177″	70mm	2-3/4″	50 pcs	7.6g
SCM80	4.5mm	0.185″	80mm	3-3/16″	36 pcs	10.41g
SCM100	4.5mm	0.185″	100mm	4″	23 pcs	16.5g
SCM125	5.0mm	0.197″	125mm	5″	17 pcs	21.54g
SCM150	5.0mm	0.0197	150mm	6″	14 pcs	25.85g
